Test method

1 point  end, 2 point end(Sample blank), Kinetics, Fixed-time, Coagulation(optional).

Optics

7 standard  filters: 340nm, 405nm, 450nm, 505nm, 546nm, 578nm, 630nm. 2 more for  optional.

Lamp house

Long-life  tungsten halogen lamp(6V/10W); auto-sleep function.

Display

7.0"  TFT LCD with touch screen, 800*480 pixels.

Printer

Build-in  thermal printer, 57mm printer paper.

Temperature

25, 30, 37℃ and Room temperature. By means of Peltier elements.

Flow cell  capacity & optical path

32μl,10mm.

Resolution

0.0001 Abs.

Photometric  range

0.0000-4.0000  Abs.

CPU

ARM  Cortex-A8, 720M Hz.

Memory

DDR2 SDRAM:  1G bit;

Flash

256 MB;

Over 300  programs; 200000 results can be stored.

Interface

4 USB Hosts, 1 USB Slave, 1 Ethernet  port.

USB port(host) for keyboard, mouse,  printer, U disk, barcode reader etc.

USB port(slave) for PC connection(support  PC software control function).

Operational  environment Temperature

10°C~30°C,  Humidity: 30%~80%.

Power  requirement

Wide power  supply AC 100-240V, 50/60 Hz.

Dimension

400*300*160mm(L*W*H).
